General Information
Brand
Klein Tools
Part Number
VDV226-011-SEN
Product Type
Crimper/Stripper
Application
Cable Connection
Packaging
Retail
UPC
092644580147
California Residents
Proposition 65 Warning
Physical Characteristics
Length
7.5'' (190.5 mm)
Weight
0.05 kg
0.10 lb
Color
Yellow / Black
Material
Steel with Black Oxide
Details
Features
Fast, reliable modular-crimp connector installation for voice and data applications
All-In-One Tool, cuts, strips and crimps paired-conductor cables (round STP/UTP and flat-satin phone cable)
Crimps 4, 6, and 8 position modular connectors (RJ22, RJ11/RJ12, and RJ45)
Steel body with black-oxide finish for excellent performance and durability
Crimping dies are precision ground from high-carbon steel
Designed for Western Electric (WE)/Stewart Stamping (SS)-type modular connectors
Ratchet safety-release and a blade-guard on cutting and stripping knives reduce risk of injury
Full-cycle ratchet mechanism prevents the release of the connector prior to full compression
Yellow and black grips enhance comfort, visibility, and allow quick identification
Three crimping dies (8-position, 6-position and 4-position)
Cable parameters: 28-22 AWG (.08 - .34 mm) flat or round; solid or stranded telephone and data
Not for use with AMP connectors
AMP is a registered trademark of TYCO, Inc.
Replacement blade set available (Cat. No. VDV999-064)
All-In-One Tool, cuts, strips and crimps paired-conductor cables (round STP/UTP and flat-satin phone cable)
Crimps 4, 6, and 8 position modular connectors (RJ22, RJ11/RJ12, and RJ45)
Steel body with black-oxide finish for excellent performance and durability
Crimping dies are precision ground from high-carbon steel
Designed for Western Electric (WE)/Stewart Stamping (SS)-type modular connectors
Ratchet safety-release and a blade-guard on cutting and stripping knives reduce risk of injury
Full-cycle ratchet mechanism prevents the release of the connector prior to full compression
Yellow and black grips enhance comfort, visibility, and allow quick identification
Three crimping dies (8-position, 6-position and 4-position)
Cable parameters: 28-22 AWG (.08 - .34 mm) flat or round; solid or stranded telephone and data
Not for use with AMP connectors
AMP is a registered trademark of TYCO, Inc.
Replacement blade set available (Cat. No. VDV999-064)
